PSI-TERMINATOR-PB Phoenix Processor module

Description Brand：Phoenix Contact            Model number： PSI-TERMINATOR-PB Colour：new                                   Warranty: 12 months Lead Time：3-day working day   Country of origin: Germany Price: Please contact us         Product weight：2.5kg Product Dimensions： Active termination resistor for PROFIBUS and RS-485 networks PSI-TERMINATOR-PB © PHOENIX CONTACT Data sheet PROFIBUS and other RS-485 2-wire networks can be actively terminated at the bus end using the PSI-TERMINATOR-PB. This ensures safe communication even if the bus device is connected/disconnected during operation. In addition, the device can be operated as an electrically isolated service interface. The alternative D-SUB connection is used as a power supply for an active programming device. The bus connection takes place via a plug-in double connection terminal block or alternatively via a D-SUB socket. Separate LED displays are available to the user for voltage supply and bus activity diagnostics. An extended temperature range of -20 °C to 65 °C and a compact housing with a width of 22.5 mm allows use under industrial environmental conditions and in confined spaces. Features – PROFIBUS up to 12 Mbps – electrical isolation of supply and data interface – switchable termination – 24 V DC supply voltage – Programming interface for active and passive programming devices – 22.5 mm wide, 54 mm high – large temperature range of -20 °C to 65 °C – Diagnostics LEDs for VCC and data activity – Mounted on EN DIN rails – two shield clips supplied as standard WARNING: Explosion hazard when used in potentially explosive areas The device is a category 3 item of electrical equipment. Follow the instructions provided here during installation and observe the safety notes. Make sure you always use the latest documentation Shipping Port: Xiamen, China Payment: Bank of Chicago, Bank of Singapore Express cooperation: fedex, DHL, UPS and your express account Service: Professional Sales provides 24 hours /7 days online service Please make an inquiry for more models： PHOENIX UMK-SE PHOENIX 947-7 PHOENIX MCR-DAC12/U-10/MSTB PHOENIX QUINT-PS-100-240VAC PHOENIX QUINT-BUFFER-24DC/20 PHOENIX QUINT-PS-100-240AC/10 PHOENIX QUINT-PS-100-240AC/24DC/10 PHOENIX UMK-SE11.25-1 PHOENIX PLC-BSC-24DC/21 PHOENIX HDFK4 PHOENIX UK3N PHOENIX UK4-T PHOENIX UK6N PHOENIX ST6 PHOENIX MINI-PS-12-24DC/24DC/1 PHOENIX ILC-150-ETH PHOENIX 2751687 PHOENIX 2752000 PHOENIX 90-PS-120AC/2X15DC/1 PHOENIX CM125-PS-120-230AC/24DC/5/F PHOENIX CONTCAT IBS PCI SC/I-T PHOENIX CPU-IB IL332-128-PAC PHOENIX D-32825 PHOENIX E/UK PHOENIX EMG10-REL/KSR-G24/21-LC PHOENIX FL SWITCH MM HS PHOENIX IB IL 24 DI 16 PHOENIX IB IL 24 DO 16 PHOENIX IB IL AI 2/SF PHOENIX IB IL AO 2/U/BP PHOENIX IB STME 24 AI 4/SF PHOENIX IB-IL-RS-485/422-PAC PHOENIX IBS 24 BK-T PHOENIX IBS 24BK/LC2 PHOENIX IBS 24DI/32 PHOENIX IBS 24DO/32 PHOENIX IBS PCI SC/I-T PHOENIX IBS S5 DAB PHOENIX IBS S5 DSC/I-T PHOENIX IBS24 BK-T(2780797) PHOENIX INTERBUS IBS S5 DAB PHOENIX MCR-PS-24DC-10DC PHOENIX MCR-R/I-4-V-DC PHOENIX OTTA 6-T PHOENIX PI-EX-ME-RPS-I/I PHOENIX PLC-RSC-24DC/21 PHOENIX PSR-URM4/5X1-B PHOENIX QUINT-DC-UPS/24DC/10 PHOENIX QUINT-PS/1AC/24DC/10 PHOENIX QUINT-PS/1AC/24DC/20 PHOENIX QUINT-PS-100-240AC/24DC/110 PHOENIX QUINT-PS-100-240AC/24DC/20 PHOENIX QUINT-PS-100-240VAC/24VDC/20 PHOENIX QUINT-PS-3*400-500AC PHOENIX STEP-PS/1AC/24DC/2.5 PHOENIX ST-SI-UK4 PHOENIX SUBCON-PLUS-PROFIB/PG/SC2 PHOENIX SUBCON-PLUS-PROFIB/SC2 PHOENIX UK 2.5 B PHOENIX UM72-R-230UC/21-21/S046 PHOENIX UT 4-HE SI PHOENIX UT 4-MTD PHOENIX UT 6-HE SI PHOENIX OCM-DPR-85-D-ST PHOENIX QUINT PS-100-240AC/24DC/10 PHOENIX FLMC10BASE-T/FO G850 PHOENIX IBS 24BK-I/O-T PHOENIX FLKM50-PA-AB/1756 PHOENIX 2961192 PHOENIX OPC5315-004-AB PHOENIX IB ST 24 AI 4/SF-2754309 PHOENIX IB ST ZF 24 AI 4/SF-2750620 PHOENIX EZ-DR PHOENIX UT 4-TG PHOENIX ILB BT ADIO MUX-OMNI PHOENIX PT-BE/FM PHOENIX ST 1.5-TWIN PHOENIX ST 2.5-TWIN PHOENIX ST 4-TWIN PHOENIX OCM-DPR-85-P-D-ST-ACV PHOENIX FL-SWITCH-MCS-14TX/2FX PHOENIX OCM-ETH-85-D-ST-A1-EXT PHOENIX IBS-IP-ODP2 PHOENIX OCX-CTN-13-R-D-ST-ACV PHOENIX OCX-CTN-85-R-D-ST-24V PHOENIX IBS-IP-500-PS-2-BS PHOENIX IBS-ISA-SC/486DX/I-T PHOENIX OPC5515-003-AB PHOENIX VME-3H-CB/I-T PHOENIX 0405-6300G1 PHOENIX OCM-DPR-13-D-ST PHOENIX OCX-CTN-13D-ST PHOENIX OCX-ETF-13-D-ST-2A1-SM-EXT PHOENIX PPC-5315-S PHOENIX PPC5315 PHOENIX PLC-BSC-24DC/21 NO.#2961105 PHOENIX PLC-BSC-24DC/21 NO.#2961192
