SACB-8/16-10,0PUR .SCOP PHOENIX Sensor/Actuator Box

Description SACB-8/16-10,0PUR .SCOP PHOENIX Sensor/Actuator Box(8-slot, 10m Cable) Product Dimensions： Product Description (Detailed Explanation) This distribution box acts as a centralized hub for field-level wiring. Instead of running 16 separate cables from sensors back to a control cabinet, technicians connect sensors directly to this box via M12 connectors. High Signal Density: It features 8 slots, but since each slot is double-occupied (supporting two signals per M12 port), it can handle a total of 16 signals. Pre-Assembled Cable: The unit comes with a permanently connected 10-meter PUR cable, eliminating the need for manual wiring of the master branch. SPEEDCON Technology: It utilizes the “SCO” (SPEEDCON) rapid locking system, allowing M12 connections to be secured with just a half-turn, significantly reducing assembly time. Product Parameters (Technical Specifications) Parameter Category Specification Number of Slots 8 Slots (M12 female connectors) Total Number of Signals 16 (2 signals per slot) Cable Length 10 Meters Cable Material PUR (Polyurethane) – Halogen-free Nominal Voltage 120 V AC/DC Current Carrying Capacity 2 A (per signal) / 4 A (per slot) / 12 A (Total) Protection Rating IP65 / IP67 Connection Method M12 SPEEDCON (SCO) Operating Temperature $-25^\circ C$ to $ 80^\circ C$ (Cable fixed) Product Advantages (Key Benefits) Reduced Installation Time: The SPEEDCON system and pre-wired master cable allow for lightning-fast setup compared to traditional terminal block wiring. Space Optimization: Consolidation of 16 signals into one 10-meter cable saves significant space in cable trays and cabinet entry points. Industrial Durability: The PUR cable jacket is highly resistant to oils, coolants, and mechanical wear, making it ideal for machine tool environments. Error Prevention: M12 connectors are keyed, which virtually eliminates the risk of cross-wiring sensors during field replacement. Clear Diagnostics: Many versions include integrated LED status indicators (check specific sub-model) for power and signal status at each port. Precautions (Important Notes) Bending Radius: When routing the 10-meter master cable, ensure the minimum bending radius is maintained (typically $10\ \times$ the cable diameter) to prevent internal wire fatigue. Tightening Torque: While SPEEDCON is fast, ensure connectors are fully engaged to maintain the IP67 waterproof seal. Unused slots should be sealed with M12 plastic screw caps. Current Limits: Do not exceed the 12 A total current limit for the entire box. High-power actuators should be powered separately or via different modules. Cable Handling: PUR is tough, but avoid dragging the cable over sharp metal edges during installation to prevent slicing the outer jacket. Product Applications (Typical Use Cases) Machine Tool Construction: Connecting limit switches, proximity sensors, and solenoid valves on CNC milling or turning centers. Automotive Assembly Lines: Consolidating signals from inductive sensors and small actuators along robotic conveyor systems. Packaging Machinery: Managing high-speed sensors on pick-and-place machines where a compact footprint is required. Conveyor Systems: Linking multiple photo-eye sensors across long distances back to a central PLC cabinet.   Shipping Port: Xiamen, China Payment: Bank of Chicago, Bank of Singapore Express cooperation: fedex, DHL, UPS and your express account Service: Professional Sales provides 24 hours /7 days online service Please make an inquiry for more models： PHOENIX UMK-SE PHOENIX 947-7 PHOENIX MCR-DAC12/U-10/MSTB PHOENIX QUINT-PS-100-240VAC PHOENIX QUINT-BUFFER-24DC/20 PHOENIX QUINT-PS-100-240AC/10 PHOENIX QUINT-PS-100-240AC/24DC/10 PHOENIX UMK-SE11.25-1 PHOENIX PLC-BSC-24DC/21 PHOENIX HDFK4 PHOENIX UK3N PHOENIX UK4-T PHOENIX UK6N PHOENIX ST6 PHOENIX MINI-PS-12-24DC/24DC/1 PHOENIX ILC-150-ETH PHOENIX 2751687 PHOENIX 2752000 PHOENIX 90-PS-120AC/2X15DC/1 PHOENIX CM125-PS-120-230AC/24DC/5/F PHOENIX CONTCAT IBS PCI SC/I-T PHOENIX CPU-IB IL332-128-PAC PHOENIX D-32825 PHOENIX E/UK PHOENIX EMG10-REL/KSR-G24/21-LC PHOENIX FL SWITCH MM HS PHOENIX IB IL 24 DI 16 PHOENIX IB IL 24 DO 16 PHOENIX IB IL AI 2/SF PHOENIX IB IL AO 2/U/BP PHOENIX IB STME 24 AI 4/SF PHOENIX IB-IL-RS-485/422-PAC PHOENIX IBS 24 BK-T PHOENIX IBS 24BK/LC2 PHOENIX IBS 24DI/32 PHOENIX IBS 24DO/32 PHOENIX IBS PCI SC/I-T PHOENIX IBS S5 DAB PHOENIX IBS S5 DSC/I-T PHOENIX IBS24 BK-T(2780797) PHOENIX INTERBUS IBS S5 DAB PHOENIX MCR-PS-24DC-10DC PHOENIX MCR-R/I-4-V-DC PHOENIX OTTA 6-T PHOENIX PI-EX-ME-RPS-I/I PHOENIX PLC-RSC-24DC/21 PHOENIX PSR-URM4/5X1-B PHOENIX QUINT-DC-UPS/24DC/10 PHOENIX QUINT-PS/1AC/24DC/10 PHOENIX QUINT-PS/1AC/24DC/20 PHOENIX QUINT-PS-100-240AC/24DC/110 PHOENIX QUINT-PS-100-240AC/24DC/20 PHOENIX QUINT-PS-100-240VAC/24VDC/20 PHOENIX QUINT-PS-3*400-500AC PHOENIX STEP-PS/1AC/24DC/2.5 PHOENIX ST-SI-UK4 PHOENIX SUBCON-PLUS-PROFIB/PG/SC2 PHOENIX SUBCON-PLUS-PROFIB/SC2 PHOENIX UK 2.5 B PHOENIX UM72-R-230UC/21-21/S046 PHOENIX UT 4-HE SI PHOENIX UT 4-MTD PHOENIX UT 6-HE SI PHOENIX OCM-DPR-85-D-ST PHOENIX QUINT PS-100-240AC/24DC/10 PHOENIX FLMC10BASE-T/FO G850 PHOENIX IBS 24BK-I/O-T PHOENIX FLKM50-PA-AB/1756 PHOENIX 2961192 PHOENIX OPC5315-004-AB PHOENIX IB ST 24 AI 4/SF-2754309 PHOENIX IB ST ZF 24 AI 4/SF-2750620 PHOENIX EZ-DR PHOENIX UT 4-TG PHOENIX ILB BT ADIO MUX-OMNI PHOENIX PT-BE/FM PHOENIX ST 1.5-TWIN PHOENIX ST 2.5-TWIN PHOENIX ST 4-TWIN PHOENIX OCM-DPR-85-P-D-ST-ACV PHOENIX FL-SWITCH-MCS-14TX/2FX PHOENIX OCM-ETH-85-D-ST-A1-EXT PHOENIX IBS-IP-ODP2 PHOENIX OCX-CTN-13-R-D-ST-ACV PHOENIX OCX-CTN-85-R-D-ST-24V PHOENIX IBS-IP-500-PS-2-BS PHOENIX IBS-ISA-SC/486DX/I-T PHOENIX OPC5515-003-AB PHOENIX VME-3H-CB/I-T PHOENIX 0405-6300G1 PHOENIX OCM-DPR-13-D-ST PHOENIX OCX-CTN-13D-ST PHOENIX OCX-ETF-13-D-ST-2A1-SM-EXT PHOENIX PPC-5315-S PHOENIX PPC5315 PHOENIX PLC-BSC-24DC/21 NO.#2961105 PHOENIX PLC-BSC-24DC/21 NO.#2961192
